Matter: A Unified Approach to IoT Device Development

Matter simplifies development by driving the convergence between the major IoT ecosystems with a reliable and secure wireless protocol built on proven IP-based technologies, designed to connect devices across ecosystems and manufacturers.

Start Building with Matter







0:00 / 0:35



Matter SoC and Module Selector Guide

Our Matter SoC and Module Selector Guide provides you with a quick, comparative overview of our portfolio to help you select the ideal SoC or module for your next project.

Browse Selector Guide

Get Started on Your Matter Developer Journey

We can accelerate the development of Matter devices by helping you along each stage of your project, including guiding you along the path of key ecosystem providers.

Begin Developing

Matter Frequently Asked Questions

We’ve collected the most common questions about the Matter standard, what it means for developers, and how to make the most of its potential.

Download the Matter FAQ



1.
   Hardware
2.
   Kits and Boards
3.
   Demos
4.
   Applications
5.
   About Matter



Wi-Fi 6 SoCs and Modules 2 Select Columns

Frequency Bands Application MCU Onboard IP Support Key Peripherals

SiWx915 Wireless SoCs Wi-Fi 6 plus and Bluetooth LE 5.4	Single Band (2.4)			SDIO, UART, SPI, SDIO
SiWx917 Wireless SoCs Wi-Fi 6 plus and Bluetooth LE 5.4	Single Band (2.4)			SDIO, SDIO, SPI, SDIO, SPI, UART



Thread SoCs and Modules 5 Select Columns

Thread Certified Frequency Bands (MHz) Flash (kB) RAM (kB) Output Power Range (dBm) MCU Core TX Current (mA) 0 dBm RX Current (mA) RX Sensitivity (dBm) Security GPIO

FEATURED EFR32MG26 Series 2 SoCs EFR32MG26 Series 2 SoCs		2.4 GHz	3200	512	-20 19.5	ARM Cortex-M33	6	6.2	-105.4	AES-128  AES-256  ECC  SHA-1  SHA-2  Secure Enclave	28, 32, 49, 64
EFR32MG24 Series 2 SoCs MGM240 Modules		2.4 GHz	1024, 1536	128, 192, 256	-20 10,19.5	ARM Cortex-M33	5.0	5.1	-105.4 (802.15.4)	AES-128  AES-256  ECC  SHA-1  SHA-2  Secure Enclave	26, 28, 32
EFR32MG24 Series 2 Modules MGM240 Modules		2.4 GHz	1536	192, 256	-33.7,-29.1,-24,-23.8 10,19.9	ARM Cortex-M33	4.8	5.2, 5.9, 7.7	-106 (802.15.4)	AES-128  AES-256  ECC  SHA-1  SHA-2	12, 26, 32
EFR32MG21 Series 2 SoCs Zigbee and Thread EFR32MG21 SoCs (Series 2)		2.4 GHz	512, 768, 1024	64, 96	-20 10,10.5,20	ARM Cortex-M33	9.9	9.4	-104.3 (250 kbps O-QPSK DSSS)	AES-128  AES-256  ECC  SHA-1  SHA-2	20
EFR32MG21 Series 2 Modules Zigbee and Thread EFR32MG21 Based Modules (Series 2)		2.4 GHz	1024	96	-20 10,12.5,20	ARM Cortex-M33	16.1	9.4	-104 (802.15.4)	AES-128  AES-256  ECC  SHA-1  SHA-2	20



Wi-Fi 4 SoCs and Modules 4 Select Columns

Frequency Bands Application MCU Onboard IP Support Key Peripherals

RS9116 Wi-Fi NCP SoCs RS9116 Wi-Fi NCP SoCs	Single Band (2.4)			UART, SPI, SDIO, USB CDC
RS9116 Wi-Fi NCP Modules RS9116 Wi-Fi NCP Modules	Dual Band (2.4/5), Single Band (2.4)			UART, SPI, SDIO, USB CDC
WF200 Series 2 Wi-Fi Transceiver Modules WFM200 Wi-Fi Transceiver Modules (Series 2)	Single Band (2.4)			SDIO/SPI
WF200 Series 2 Wi-Fi Transceiver SoCs Wi-Fi Transceiver SoCs (Series 2)	Single Band (2.4)			SDIO, SPI
